LaserPro ™ Laser-Cuttable Film

LaserPro ™ laser-cuttable film is a family of polyester films which has been specially coated for more efficient laser fabrication.  It’s our special coating that makes this film so laser-cuttable. The coating allows stacks of sheets to be laser cut without the film permanently welding to itself, so multiple copies can be fabricated simultaneously. Grafix Plastics offers a wide variety of stock LaserPro products, and can also custom top-coat any type of oriented polyester base film with our proprietary coating.  On a custom basis, we can make any polyester film to be laser-cuttable!



Features


Features of LaserPro film and sheets:

  • Dimensional stability
  • Multi-sheet cutting capability
  • Tear-resistant polyester base film
  • Lay flat
  • Chemical resistance
  • Heat resistant to 200° C
  • Good clarity
  • Good electrical insulating
  • Custom colors available

Types


LaserPro offers you plenty of choices*:

  • Stock Options
  • Blue Transparent
  • Translucent / Hazy
  • Gauges
  • .005″
  • .007″ (Blue Only)
  • .010″

*Not all finishes are available for each gauge and size

Stock


Need to get something quickly? We’ve got you covered with materials in stock and ready to go.

Raw materials

Master Roll (by width)

  • .005″, .010″ Hazy Laser, stocked >50″ Master Rolls
  • .007″ Blue Stencil, stocked at 52″ wide Master Rolls

We can turn any thickness of Polyester into laser cuttable film from .001″ to .010″ thick. Minimum order quantities may apply. Contact us today for more details.

Finished Goods

Sheets

  • Our laser : 9″x12″, 12″x24″, 18″x24″ and 24″x36″
  • Custom sized sheets from 54″x60″ down to 1″x1″ can be produced


Custom sizes and configurations are available with certain minimum quantities ordered.

Specs

Properties are based on .005″/125um general use Duralar polyester film base, because that is what LaserPro is made from. Properties of other gauges and finishes of LaserPro film can vary.

General DuraLar Spec Sheet

Film PropertyValueUnitsTest Method
Physical Properties
Tensile Strength (MD)28,000psiASTM D 882
Tensile Strength (TD)34,000psiASTM D 882
Strength Elongation MD15,000psiASTM D 882
Strength F-5 TD14,000psiASTM D 882
Modulus MD710,000psiASTM D 882
Modulus TD740,000psiASTM D 882
Elongation MD115%ASTM D 882
Elongation TD92%ASTM D 882
Density1.39g/ccASTM D 1505
Viscosity0.56dL/gASTM D 4603
Electrical Properties
Dielectric Strength
AC, 20°C, .00092"7,000volts/milASTM D 149-64
Dielectric Constant
25°C, 1 kHz3.2ASTM D150-81
Dissipation Factor
25°C, 1 kHz0.005ASTM D150-65
Volume Resistivity 25°C1.00E+19ohm-cmASTM D257-78
Corona Threshold425V-ACASTM D2275-80
Thermal Properties
Melt Point200
Service Temperature Range -70-150C
Dimensional Stability
at 105° MD0.6%Measured Shrinkage
at 105° TD0.9%Measured Shrinkage
at 150° MD1.8%Measured Shrinkage
at 150° TD1.1%Measured Shrinkage
Specific Heat0.28
Thermal Expansion1.7x10-5ASTM D 696
Optical Properties
Transmission Visible> 88%
Transmission Near IR>80%
Haze<1%
Refractive Index1.65RI
Chemical Properties
Resistance by Class
AcidsGood
BasesGood
SolventsExcellent
DetergentsExcellent
OilsGood
Permeability
Water Vapor 0.1g/100 in2/24hr.ASTM E-96
Carbon Dioxide16g/100 in2/24hr.ASTM D1434-58
Moisture Absorption<.8%ASTM D-570-63
Stain ResistanceMost Household Agents & Chemicals
Table from Product Spec Sheet XLS



For more specific questions regarding DuraLar Film or LaserPro Film, please contact your sales representitive today!

Important Notice:  Grafix makes no warranties, express or implied, including but not limited to any implied warranty of merchantability of fitness for a particular purpose.  The user is responsible for determining whether the Grafix product is fit for a particular purpose and suitable for the user’s method of application.  Please remember that many factors can affect the use and performance of a Grafix Plastics film product in a particular application.  Given the variety of factors that can affect the use and performance of a Grafix product, some of which are uniquely within the user’s knowledge and control, it is essential that the user evaluate the Grafix product to determine whether it is fit for a particular purpose and suitable for the user’s method of application.
Limitation of Remedies and Liability:  If the Grafix product is proven to be defective, THE EXCLUSIVE REMEDY, AT GRAFIX’S OPTION, SHALL BE TO REFUND THE PURCHASE PRICE OF OR TO REPAIR OR REPLACE THE DEFECTIVE GRAFIX PRODUCT. Grafix shall not otherwise be liable for loss or damages, whether direct, indirect, special, incidental or consequential, regardless of the legal theory asserted, including, but not limited to, contract, negligence, warranty or strict liability.

Safety


  • DEHP, DBP and BBP free. Contact us for more details
  • RoHS Compliant
